Electrical and Avionics

Aircraft/Engine Systems (video)
by George Orndorff
2 tapes / 3 hours
VHS  - $46.50



acsystms.tif (1038317 bytes) Although based around a Lycoming 0-360 equipped RV-6A, this video is extremely relevant to the finishing or restoration of almost any high performance homebuilt aircraft, certainly including RVs, Lancairs, Glasairs, GlaStars, etc... This is an area to which most kit plane manufacturers offer little assistance in their plans and manuals citing "every installation is different and the builder needs to make their own choices". While that may be true, the fundamental decisions and techniques involved are the same for us all.

In this video, George Orndorff, a highly experienced builder of several aircraft, takes you step by step through each of the system installations which are a part of every aircraft. Here is some of what is covered:





ENGINE SYSTEMS
1] Engine cooling systems. (assembling baffles and fitting them to the cowl)
2] Oil cooler placement and installation, including oil lines
3] Accessory cooling tube placement and installation
4] Throttle, mixture and prop control cables
5] Engine instrument sender installations
6] Vacuum pump installation
7] Fuel system. (gascolator, primer, fuel lines, firesleeve, etc...)
8] Cabin heat baffles and control
9] Constructing hoses

ELECTRICAL & PANEL
1] Construction of the panel and a dampened sub-panel
2] Placing and mounting instruments, switches, and circuit breakers
3] Electrical systems wiring and good connectors
4] Wiring the ignition, starter systems, and solenoids
5] Antenna place

OTHER SYSTEMS
1] Bleeding brakes
2] Sound proofing
3] Cabin ventilation system
4] A little on paint prep, painting, and striping


This video is an excellent compliment to:
Tony Bingelis - On Engines
